1000VA / 550W 165-280Vac, USB & Serial; AVR
|
Model |
VALUE1000EI-AS |
|
Capacity (VA/Watts) |
1000VA / 550W |
|
Input |
|
|
Frequency Range |
47 ~ 63 Hz (Auto Sensing) |
|
Input Plug Type |
IEC 320 C14 |
|
Output |
|
|
UPS Outlets (Numbers) |
(3) AS |
|
On Battery Output Voltage |
Simulated SineWave at 230Vac +/- 5% |
|
On Battery Output Frequency |
50Hz / 60 Hz +/- 1% |
|
Transfer Time (Typical) |
8ms |
|
Overload Protection |
On Utility: Fuse & Internal Current Limiting / On Battery: Internal Current Limiting |
|
AVR |
Boost & Buck |
|
Surge Protection and Filtering |
|
|
Lightning/Surge Protection |
Yes |
|
Battery |
|
|
Sealed Maintenance Free Lead Acid Battery |
12V 9AH x 1 |
|
Typical Recharge Time |
8 Hours |
|
Runtimes |
|
|
Half-load / Full-load (mins) |
6'15 / 1'00' |
|
Status Indicators |
|
|
Indicators |
Power On / Using Battery |
|
Audible Alarms |
On Battery, Low Battery, Overload |
|
Communication |
|
|
Power Management Software |
PowerPanel® Personal Edition |
|
Management |
|
|
Self Test |
Yes |
|
Auto-Charge / Auto-Restart |
Yes |
|
Connectivity Ports |
USB, Serial |
|
Dimensions (H x W x D) |
140 x 100 x 300 mm |
|
Weight |
5.6 kg |
