Output
Overload Protection
No
Maximum Total Current Draw
10
Output Connections
(12) IEC 320 C13 (Battery Backup)
Input
Nominal Input Voltage
200V , 208V , 230V
Input frequency
47 - 63 Hz
Input Connections
IEC-320 C14
Maximum Input Current
10A
Maximum Line Current
10A
Physical
Maximum Height
44mm , 4.4CM
Maximum Width
432mm , 43.2CM
Maximum Depth
229mm , 22.9CM
Rack Height
1U
Net Weight
3.93KG
Shipping weight
5.7KG
Shipping Height
114mm , 11.4CM
Shipping Width
600mm , 60.0CM
Shipping Depth
349mm , 34.9CM
Color
Black
Environmental
Operating Temperature
-5 - 45 °C
Operating Relative Humidity
5 - 95 %
Operating Elevation
0-3000meters
Storage Temperature
-25 - 65 °C
Storage Relative Humidity
5 - 95 %
Storage Elevation
0-15000meters
Conformance
Approvals
EN 55022 Class A, FCC Part 15 Class A
Standard warranty
2 years repair or replace
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains No SVHCs
PEP
Available in Documentation tab
EOLI
Available in Documentation tab
Battery Directive
Compliant
Other Environmental Compliance
China RoHS
