Output
Max Configurable Power (Watts) 15.0kWatts / 15.0kVA
Output Voltage Distortion Less than 3%
Output Frequency (sync to mains) 50 Hz, 60 Hz
Other Output Voltages 380, 415
Topology Double Conversion Online
Output Voltage THD < 3% linear load
Output Voltage Tolerance +/- 1.5%
Input
Input frequency 45 - 65 Hz
Input voltage range for main operations 304 - 477V
Input Total Harmonic Distortion Less than 3% for full load
Other Input Voltages 380, 415
Input Power Factor at Full Load 0.99
Batteries & Runtime
Battery type VRLA
Included Battery Modules 2
Nominal Battery Voltage 240V
Battery Slots Empty 1
Replacement battery cartridge note UPS weight does not include battery weight.
Efficiency View Efficiency Graph
Communications & Management
Interface Port(s) E3S_Parallel, E3S_TempSensor
Physical
Maximum Height 1400MM, 140.0CM
Maximum Width 380MM, 38.0CM
Maximum Depth 928MM, 92.8CM
Net Weight 436.0KG
Shipping weight 481.0KG
Shipping Height 1640MM, 164.0CM
Shipping Width 563MM, 56.3CM
Shipping Depth 1014MM, 101.4CM
Color
White
Environmental
Operating Temperature 0 - 40 °C
Operating Relative Humidity 0 - 95 (non-condensing) %
Operating Elevation 0-999.9meters
Storage Temperature -15 - 40 °C
Storage Relative Humidity 0 - 95 (non-condensing) %
Storage Elevation 0-15000meters
Audible noise at 1 meter from surface of unit 60.0dBA
Online thermal dissipation 852.0BTU/hr
Protection Class IP 20
Conformance
Approvals CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE
Standard warranty 1 year on-site repair or replace with factory authorized Start-Up
Sustainable Offer Status
RoHS Compliant
REACH REACH: Contains No SVHCs
