Output
Nominal Output Voltage
230V
Overload Protection
Yes
Maximum Total Current Draw
32
Output Connections
(36) IEC 320 C13 (Battery Backup)
(6) IEC 320 C19 (Battery Backup)
Input
Nominal Input Voltage
200V , 208V , 230V
Input frequency
50/60 Hz
Input Connections
IEC 309 32A 2P+E
Cord Length
3meters
Acceptable Input Voltage
220-240VAC
Number of Power Cords
1
Maximum Input Current
32A
Maximum Line Current
32A
Physical
Maximum Height
1791mm , 179.1CM
Maximum Width
56mm , 5.6CM
Maximum Depth
44mm , 4.4CM
Net Weight
6.93KG
Shipping weight
8.56KG
Shipping Height
2000mm , 200.0CM
Shipping Width
162mm , 16.2CM
Shipping Depth
107mm , 10.7CM
Color
Black
Units per Pallet
48.0
Environmental
Operating Temperature
-5 - 45 °C
Operating Relative Humidity
5 - 95 %
Operating Elevation
0-3000meters
Storage Temperature
-25 - 65 °C
Storage Relative Humidity
5 - 95 %
Storage Elevation
0-15000meters
Conformance
Approvals
IEC 60950, VDE
Standard warranty
2 years repair or replace
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains No SVHCs
PEP
Available in Documentation tab
EOLI
Available in Documentation tab
Battery Directive
Compliant
