Output
Output power capacity
720Watts / 1.2 kVA
Max Configurable Power (Watts)
720Watts / 1.2 kVA
Nominal Output Voltage
230V
Output Frequency (sync to mains)
50 Hz, 60 Hz
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal, 50Hz +/- 0.1% for 50Hz nominal
Load Crest Factor
3 : 1
Topology
Line Interactive
Waveform type
Stepped approximation to a sinewave
Output Connections
(5) IEC 320 C13 (selector_surgetitle)
(5) IEC 320 C13 (Battery Backup)
(2) IEC Jumpers (Battery Backup)
Transfer Time
10ms typical : 12ms maximum
Input
Nominal Input Voltage
230V
Input frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
IEC-320 C14
Input voltage range for main operations
176 - 294V
Input voltage adjustable range for mains operation
156 - 300V
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time
8hour(s)
Replacement Battery
APCRBC124
Expected Battery Life (years)
3 - 5
RBC Quantity
1
Runtime
View Runtime Graph
View Runtime Chart
Efficiency
View Efficiency Graph
Communications & Management
Interface Port(s)
Optional Simple Signalling RS232 cable , USB
Control panel
Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating
441Joules
Data Line Protection
Analog phone line for phone/fax/modem/DSL (RJ-11 connector), Network line - 10/100/1000 Base-T Ethernet (RJ-45 connector)
Filtering
Full time multi-pole noise filtering :10% of IEEE surge let-thgouh : zero clamping response time: instantaneous
Physical
Maximum Height
301mm , 30.1CM
Maximum Width
112mm , 11.2CM
Maximum Depth
380mm , 38.0CM
Net Weight
11.6KG
Shipping weight
13.2KG
Shipping Height
387mm , 38.7CM
Shipping Width
238mm , 23.8CM
Shipping Depth
488mm , 48.8CM
Color
Black
Master Carton Units
1.0
Units per Pallet
24.0
SCC Codes
1073130426875 5
Environmental
Operating Temperature
0 - 40 °C
Operating Relative Humidity
0 - 95 %
Operating Elevation
0-9000meters
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
0 - 95 %
Storage Elevation
0-15000meters
Audible noise at 1 meter from surface of unit
45.0dBA
Conformance
Approvals
A-tick, C-tick, CE, GOST, GS Mark, Telepermit, TUV
Equipment protection policy
Lifetime : 200000 AUD, Lifetime : 150000 Euros, Lifetime : 75000 GBP
Standard warranty
2 years repair or replace, 3 years repair or replace for European Union countries
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains No SVHCs
PEP
Available in Documentation tab
EOLI
Available in Documentation tab
