Output
Output power capacity
330Watts / 550VA
Max Configurable Power (Watts)
330Watts / 550VA
Nominal Output Voltage
230V
Output Frequency (sync to mains)
50 Hz
Topology
Line Interactive
Waveform type
Stepped approximation to a sinewave
Output Connections
(3) IEC 320 C13 (selector_surgetitle)
(3) IEC 320 C13 (Battery Backup)
(2) IEC Jumpers (Battery Backup)
Transfer Time
6ms typical : 10ms maximum
Input
Nominal Input Voltage
230V
Input frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
IEC-320 C14
Input voltage range for main operations
176 - 282V
Input voltage adjustable range for mains operation
155 - 290V
Maximum Input Current
6.0A
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time
12hour(s)
Replacement Battery
APCRBC110
Expected Battery Life (years)
3 - 5
RBC Quantity
1
Runtime
View Runtime Graph
View Runtime Chart
Efficiency
View Efficiency Graph
Communications & Management
Interface Port(s)
Optional Simple Signalling RS232 cable , USB
Control panel
Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating
420Joules
Data Line Protection
Network line - 10/100/1000 Base-T Ethernet (RJ-45 connector)
Filtering
Full time multi-pole noise filtering :10% of IEEE surge let-thgouh : zero clamping response time: instantaneous
Physical
Maximum Height
190mm , 19.0CM
Maximum Width
91mm , 9.1CM
Maximum Depth
310mm , 31.0CM
Net Weight
6.53KG
Shipping weight
7.71KG
Shipping Height
252mm , 25.2CM
Shipping Width
138mm , 13.8CM
Shipping Depth
442mm , 44.2CM
Color
Black
Master Carton Units
2.0
Master Carton Weight
15.94
Units per Pallet
48.0
SCC Codes
1073130426688 1
Environmental
Operating Temperature
0 - 40 °C
Operating Relative Humidity
0 - 95 %
Operating Elevation
0-3000meters
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
0 - 95 %
Storage Elevation
0-15000meters
Audible noise at 1 meter from surface of unit
45.0dBA
Conformance
Approvals
A-tick, C-tick, CE, GOST, GS Mark
Equipment protection policy
Lifetime : 200000 AUD, Lifetime : 150000 Euros, Lifetime : 75000 GBP
Standard warranty
2 years repair or replace, 3 years repair or replace for European Union countries
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains No SVHCs
PEP
Available in Documentation tab
EOLI
Available in Documentation tab
