Output
Output power capacity
4.0 KWatts / 5.0 kVA
Max Configurable Power (Watts)
4.0 KWatts / 5.0 kVA
Nominal Output Voltage
230V
Output Voltage Note
Configurable for 220 : 230 or 240 nominal output voltage
Efficiency at Full Load
96.0 %
Output Voltage Distortion
Less than 5% at full load
Output Frequency (sync to mains)
47 - 53 Hz for 50 Hz nominal
Other Output Voltages
220, 240
Topology
Line Interactive
Waveform type
Sine wave
Output Connections
(4) IEC Jumpers (Battery Backup)
(2) IEC 320 C19 (Battery Backup)
(8) IEC 320 C13 (Battery Backup)
Transfer Time
2ms typical : 4ms maximum
Input
Nominal Input Voltage
230V
Input frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
Hard Wire 3-wire
Input voltage range for main operations
160 - 286V
Input voltage adjustable range for mains operation
151 - 302V
Efficiency at Full Load
96.0 %
Batteries & Runtime
Battery type
VRLA
Typical recharge time
3hour(s)
Replacement Battery
RBC55
Expected Battery Life (years)
3 - 5
RBC Quantity
2
Runtime
View Runtime Graph
View Runtime Chart
Communications & Management
Interface Port(s)
DB-9 RS-232 , SmartSlot
Pre-Installed SmartSlot™ Cards
AP9630
Control panel
LED status display with On Line : On Battery : Replace Battery and Overload indicators
Audible Alarm
Audible and visible alarms : configurable delays
Surge Protection and Filtering
Surge energy rating
480Joules
Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Maximum Height
222mm , 22.2CM
Maximum Width
483mm , 48.3CM
Maximum Depth
660mm , 66.0CM
Rack Height
5U
Net Weight
97.73KG
Shipping weight
106.82KG
Shipping Height
635mm , 63.5CM
Shipping Width
610mm , 61.0CM
Shipping Depth
762mm , 76.2CM
Color
Black
Master Carton Units
1.0
Units per Pallet
4.0
Environmental
Operating Temperature
0 - 40 °C
Operating Relative Humidity
0 - 95 %
Operating Elevation
0-3000meters
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
0 - 95 %
Storage Elevation
0-15000meters
Audible noise at 1 meter from surface of unit
53.0dBA
Online thermal dissipation
430.0BTU/hr
Conformance
Approvals
C-tick, CE, EN 50091-1, EN 50091-2, GOST, GS Mark, VDE
Equipment protection policy
--
Standard warranty
2 years repair or replace
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains No SVHCs
PEP
Available in Documentation tab
EOLI
Available in Documentation tab
Battery Directive
Compliant
Other Environmental Compliance
China RoHS
