Output
Number of Outlets
1.0
Surge Protection and Filtering
Data Line Protection
Cable modem / Video protection, Co-axial Video / Cable protection
Data Lines Protected
(multi-line only)
1
ts_nm_surge_response
1ns
Peak Current Common Mode
0.5kAmps
Peak Current Normal Mode
0.2kAmps
Physical
Maximum Height
44mm , 4.4CM
Maximum Width
19mm , 1.9CM
Maximum Depth
69mm , 6.9CM
Net Weight
0.06KG
Shipping weight
0.28KG
Shipping Height
99mm , 9.9CM
Shipping Width
33mm , 3.3CM
Shipping Depth
95mm , 9.5CM
Color
Black
Master Carton Units
96.0
SCC Codes
3073130421719 1
Environmental
Operating Temperature
-15 - 45 °C
Operating Relative Humidity
0 - 95 %
Operating Elevation
0-3000meters
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
0 - 95 %
Storage Elevation
0-3000meters
Conformance
Approvals
UL 497B, UL Recognized
Standard warranty
Lifetime
Sustainable Offer Status
RoHS
Compliant
Other Environmental Compliance
China RoHS
