Output
Nominal Output Voltage
208V , 230V
Maximum Total Current Draw
16
Output Connections
(12) IEC 320 C13 (Battery Backup)
Input
Nominal Input Voltage
200V , 208V , 230V
Input frequency
50/60 Hz
Input Connections
IEC-320 C20
Cord Length
2.5meters
Number of Power Cords
1
Load Capacity
3680VA
Maximum Input Current
16A
Physical
Maximum Height
44mm , 4.4CM
Maximum Width
447mm , 44.7CM
Maximum Depth
57mm , 5.7CM
Rack Height
1U
Net Weight
2.05KG
Shipping weight
3.64KG
Shipping Height
70mm , 7.0CM
Shipping Width
464mm , 46.4CM
Shipping Depth
229mm , 22.9CM
Color
Black
Environmental
Operating Temperature
0 - 45 °C
Operating Relative Humidity
0 - 95 %
Operating Elevation
0-3000meters
Storage Temperature
-25 - 65 °C
Storage Relative Humidity
0 - 95 %
Storage Elevation
0-15000meters
Conformance
Approvals
cUL Listed, CE, Queensland Australia, UL 60950, UL Listed, VDE
Standard warranty
2 years repair or replace
Sustainable Offer Status
PEP
Available in Documentation tab
EOLI
Available in Documentation tab
